MAIN TECHNICAL PARAMETER:
MAIN TECHICAL PARAMETER:
Working Temperature:10℃~+105℃
Capacitance Range:50μF~500μF
Rated Voltage:≤250VAC
Experimental Voltage:UR<160VUmax=l.25UR;
UR>160VUmax=1.2UR;
Capacitance Tolerance:-10%~30%
Dissipation Factor: tgδ≤0.015
Endurance Voltage between the electrodes:If from terminalec
ert1.2 UR and contnual time is 2S,it doesn't appear the
currency or is not punctured or broken down.

FEATURES AND USAGES:
●The product is produced by using high-purity electronic aluminum foil as the polar plate,using the dielectric materials of capacitor tissue and alumia.
●Adopt metal, bakelite resin or engineering plastic as shell and lug,wire of cable terminals.
●.Small volume, little loss, long life-span, wide range of capacity and voltage.
●High insulating resistance, excellent electric property,stableand dependable quality.
●This series of capacitos is ambipolar and widely used.
●It can be used in the start-up of single-phase AC motors(5OHz or 60Hz) to gain greater torsion under lower stating current.
