FEATURES AND USAGES:
MAIN TECHICAL PARAMETER:
Working Temperature:-25℃~-70℃
CapacitanceRange:0.5μF~30μF
Rated Voltage:250VAC~630VAC
CaDac_tanceTolerance:J:±5%K±10%
lnsulation Resistance:T-T≥3000MΩ.μF(20℃.100VDC)
T—c≥2000MΩ.μF(20℃.100VDC)
Dissipation Factor:tg δ≤0.002(100Hz,20℃)
EnduranceVoltage:Betweenthe electrodes:2.0Un 2S
Between the electrode and the shell:2000VAC 2S

FEATURES AND USAGES:
●None induction winding structure of metallic polypropylene membrance.
●Use round plasticshell,andinsulation sealedlidforsealing,plasticlidfor sealing or resinforsealing.
●Small volume,lightweight,low loss,excellent self-healing performance.
●Superb electric pedormance,highinsulation resistance, excellent stability of capacitance.
●Coppersolderingterminal,plastic coated copper wire and CP wire anr available.
●Itappliesto electricfan,airconditioner,electricwatre pumps and elecrtomotor,etc,with frequency 50/60Hz ,voltage, 250VAC-630VAC,and can help motors sta rt and run.
●.It can continuouslyoperate under rated conditions
