MAIN TECHNICAL PARAMETER:
Working Temperature:-25℃~70℃
Capacitance Range:4μF~100μF
Rated Voltage:450VAC~630VAC
Capacitance Tolerance:J:±5%K±10%
Insulation Resistance:T-T≥3000MΩ.μF(20℃.100VDC)
T-C≥2000MΩ.μF(20℃.100VDC)
Dissipation Factor:tgδ≤0.002 (100Hz,20℃)
Endurance Voltage:Between the electrodes:2.0Un 2S
Endurance Voltage:Between the electrodes and the shell: 2000VAC 2S

FEATURES AND USAGES:
●None induction winding structure of metallic polypropylene membrane.
●Credible insulation performance,superb electric performance with ability of self-healing and safety explosion proof equipment.
●Excellent heat dispersion, small volume, wide range of capacity, low loss stable capacitance.
●Withstand impact current, stong overload performance and long life-span.
●Suitable for starting and opetating 50Hz(60Hz)AC singlephase electromotor.
●Apply to explosion proof motor,air condition,refrigerator.
